airGrid®M

airMAX® Wireless Broadband CPE

Utilizing InnerFeed technology, the new airGrid® M HP Series from Ubiquiti Networks represents the latest evolution of outdoor wireless broadband devices. The revolutionary InnerFeed technology integrates the entire radio system into the feedhorn of the antenna. airGrid M combines Ubiquiti’s InnerFeed and airMAX® (TDMA protocol) technologies to create a simple, yet extremely powerful and robust wireless CPE (Customer Premises Equipment).

System Information

  • Processor Specs
    Atheros MIPS 74Kc, 560 MHz
  • Memory Information
    64 MB DDR2, 8 MB Flash
  • Networking Interface
    (1) 10/100 Ethernet Port

Regulatory / Compliance Information

  • Wireless Approvals
    FCC Part 15.247, IC RS210, CE
  • RoHS Compliance
    Yes

Physical / Electrical / Environmental

  • Enclosure Characteristics
    Outdoor UV Stabilized Plastic
  • Mounting Kit
    Pole Mounting Kit (Included)
  • Max. Power Consumption
    3W
  • Power Supply
    24V, 0.5A PoE Adapter (Included)
  • Power Method
    Passive Power over Ethernet (Pairs 4, 5+; 7, 8 Return)
  • Operating Temperature
    -30 to 75° C (-22 to 167° F)
  • Operating Humidity
    5 to 95% Condensing
  • Shock and Vibration
    ETSI300-019-1.4
  • ETSI Specification
    EN 302 326 DN2

AG-HP-2G16 Specifications

  • Dimensions
    370 x 270 x 270 mm(14.57 x 10.63 x 10.63")
  • Weight
    1478 g (3.258 lb)
  • Wind Survivability
    200 km/h (125 mph)
  • Wind Loading
    58 N @ 200 km/h (13 lbf @ 125 mph)
  • Operating Frequency
    2412 - 2462 MHz
  • Max. VSWR
    1.5:1
  • Gain
    16 dBi

AG-HP-2G20 Specifications

  • Dimensions
    620 x 460 x 390 mm(24.41 x 18.11 x 15.35")
  • Weight
    2603 g (5.739 lb)
  • Wind Survivability
    200 km/h (125 mph)
  • Wind Loading
    102 N @ 200 km/h (13 lbf @ 125 mph)
  • Operating Frequency
    2412 - 2462 MHz
  • Max. VSWR
    1.5:1
  • Gain
    20 dBi

AG-HP-5G23 Specifications

  • Dimensions
    370 x 270 x 260 mm(14.57 x 10.63 x 10.24")
  • Weight
    1452 g (3.201 lb)
  • Wind Survivability
    200 km/h (125 mph)
  • Wind Loading
    58 N @ 200 km/h (13 lbf @ 125 mph)
  • Operating Frequency
    5725 - 5850 MHz
  • Max. VSWR
    1.5:1
  • Gain
    23 dBi

AG-HP-5G27 Specifications

  • Dimensions
    620 x 460 x 360 mm(24.41 x 18.11 x 14.17")
  • Weight
    2585 g (5.699 lb)
  • Wind Survivability
    200 km/h (125 mph)
  • Wind Loading
    102 N @ 200 km/h (23 lbf @ 125 mph)
  • Operating Frequency
    5725 - 5850 MHz
  • Max. VSWR
    1.5:1
  • Gain
    27 dBi
